Specifications
Transyn AL4 meets or exceeds the following International and Builder specifications:
VW TL 52162
MB-Approval 236.11
ZF TE-ML 03D/04D/09/11A/11B/14A/17C
EIFFEL AL4 is designed to meet the specific requirements of automatic transmissions.
ATF is used for the AL4 and 4HP20 gearboxes as the automatic transmission fluid.
Typical Characteristics
| Transyn atf | Test Method | Units | AL4 |
|---|---|---|---|
| Color | Visual | Red | |
| Density @ 15 0C | ASTM D 4052 | gm/cc | 0.843 |
| Viscosity @ 100 0C | ASTM D 445 | cSt | 7.1 |
| Viscosity @ 40 0C | ASTM D 445 | cSt | 37.9 |
| Viscosity Index | ASTM D 2270 | – | 156 |
| Pour Point | ASTM D 97 | °C | -51 |
| Flash Point (COC) | ASTM D 92 | °C | 215 |
The above figures are typical of blends with normal production tolerance and do not constitute a specification.
